The Shure model WL93 Microphones are economical omnidirectional, subminiature, lavalier, condenser microphones designed for general speech applications where a visually unobtrusive microphone is desirable. All WL93 models are supplied with a mounting block with attached tie bar, a sew-on mounting bracket, and an acoustic windscreen to minimize wind noise in outdoor applications. All WL93 models include a cable terminated with a 4-pin mini connector which connects directly to a Shure wireless body-pack transmitter.
Shure WL93 Features:
Subminiature lavalier design; ideal size for theater, television broadcasting, video, film, and sound reinforcement
Uniform omnidirectional polar pattern
Full, clear sound comparable to larger microphones
Smooth extended frequency response with presence rise specially tailored for chest-worn microphone operation
Controlled low-frequency rolloff reduces low-frequency clothing and room noise
Low distortion, wide dynamic range
Small, inconspicuous mounting hardware.
Shure WL93 Specifications:
Transducer: Electret Condenser
Polar Pattern: Omnidirectional
Frequency Response: 80 Hz - 20 kHz
Dynamic Range (Typical): 98dB @ Max. SPL, A-Weighted
Signal-to-Noise Ratio: 72dB
Maximum Input Sound Level: 120dB @ 1 kHz,(1% THD)
Power Requirements: 2 to 10v; 5v Nominal (Pin 2 to Pins 3 and 4) (Supplied by Shure Wireless Body Transmitter Pack)
Output Impedance: 3000 ?
Output Connectors: TA4F, for Use with the Shure Wireless Transmitters
Case: Zippered Carrying Pouch
Low Frequency Roll-Off: None
Applications: Radio, Television and Broadcast, Wireless Videography.
Dimensions: .023 x 0.37" (5.84 x 9.40mm)DiameterxL
