Included Cable:
USB-C – 1m
System Sample Rate:
96kHz (with inbuilt sample rate conversion for digital inputs)
USB Connector Type:
USB-C
Bus Power Requirement:
0.9A @ 5V >=USB 3.0 Port
Measurement Mic - SNR:
65dBA
Digital Input Channels:
2
Analogue Input Channels:
2
Measurement Mic - Model:
MREF Microphone
Analogue Output Channels:
3
Measurement Mic - Weight:
54g
Measurement Mic - Max SPL:
125dBSPL
Line Output - THD+N (-1dBFS):
-113dB/0.0002%
Digital Input - Stereo S/PDIF:
44.1kHz to 96kHz
Measurement Mic - Sensitivity:
-40dBV/Pa
Line Output - Crosstalk (1kHz):
<-123dB
Line Output - Max Output Level:
+18dBu
Measurement Mic - Dynamic Range:
105dB
Measurement Mic - Polar Pattern:
Omni-directional
Measurement Mic - Connector Type:
3 Pin XLR
Measurement Mic - Microphone Type:
Electret-condenser
Measurement Mic - Transducer Type:
MEMS
Measurement Mic - Output Impedance:
330Ω
Measurement Mic - Frequency Response:
20Hz – 20kHz
Measurement Mic - Power Requirements:
+48V Phantom Power
Line Output - Dynamic Range (A Weighted):
127dB
Line Input to Line Output - THD+N (-1dBFS):
-105dB/0.0005%
Line Input to Line Output - Max Input Level:
+18dBu
Line Input to Line Output - Crosstalk (1kHz):
<-118dB
Line Output - Frequency Response (20Hz > FS/2*):
± 0.1dB
Line Input to Line Output - Dynamic Range (A Weighted):
122.5dB
Line Input to Line Output - Frequency Response (20Hz – 40kHz):
± 0.2dB
Manufacturer's Standard Warranty:
3 Year
