Audio Technica ES945 Omnidirectional Condenser Boundary Microphone

Audio Technica ES945 Omnidirectional Condenser Boundary Microphone

This item is out of stock


The new Engineered Sound. Contractor-exclusive innovations for every acoustical challenge. And safe haven from Radio Frequency Interference (RFI).

This low-profile omnidirectional condenser boundary microphone is designed for clear, highly intelligible sound reinforcement, professional recording and teleconferencing in table-, ceiling-, or panel-mount applications. The microphone is equipped with a self-contained power module with an XLRM-type output connector, eliminating the need for an external power module. The microphone offers unsurpassed immunity from radio frequency interference thanks to Audio-Technica’s UniGuard® innovations. Protected by a rugged all-metal case with a two-layer steel mesh grille, the microphone has a 360° pickup angle, and is available in two colors: black (ES945) and white (ES945W).

Audio Technica ES945 Features:
  • Designed for surface-mount applications such as high-quality sound reinforcement, professional recording and teleconferencing
  • Low-profile element provides uniform omnidirectional polar pattern with 360º acceptance angle
  • Mounts unobtrusively in table-tops, ceilings and wall panels
  • Self-contained power module with XLRM-type output connector
  • Rugged all-metal case with a two-layer steel mesh grille
  • Isolators provide mechanical dampening of mounting-surface vibration
  • Requires 11V to 52V DC phantom power
  • UniGuard® RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)
  • Available in two colors: black (ES945) and white (ES945W)
  • RoHS compliant—free from all substances specified in the EU directive on hazardous substances

Audio Technica ES945 Specifications:
  • Element: Fixed-charge back plate, permanently polarized condenser
  • Polar Pattern: Omnidirectional
  • Frequency Response: 40-18,000 Hz
  • Open Circuit Sensitivity: -42 dB (7.9 mV) re 1V at 1 Pa
  • Impedance: 200 ohms
  • Maximum Input Sound Level: 142 dB SPL, 1 kHz at 1% T.H.D.
  • Dynamic Range (typical): 112 dB, 1 kHz at Max SPL
  • Signal-To-Noise Ratio: 64 dB, 1 kHz at 1 Pa
  • Phantom Power Requirements: 11-52V DC, 2 mA typical
  • Weight: 63 g (2.2 oz)
  • Dimensions: 69.0 mm (2.72") long,
  • 28.0 mm (1.10") diameter
  • Output Connector: Integral 3-pin XLRM-type
