BSS BLU-325 Soundweb London Signal Processor with BLU Link and AVB


EMI starts from Rs. 6,809.24. Click here for options.

Shop Brand : BSS Audio
SKU : BSSBLU325

  • The Soundweb London BLU-325 offers configurable I/O, Ethernet AVB audio, and a high bandwidth, fault tolerant digital audio bus.

    The BLU-325 is configurable through HiQnet™ London Architect. A rich palette of logic objects and a “drag and drop” method of configuration provide a simple and familiar design environment.

    This processor features Ethernet AVB audio with primary and secondary ports for fault tolerance, with control through a separate Ethernet port.

    The BLU-325 also features a low latency, fault tolerant digital audio bus of 256 channels which uses standard Category 5e cabling giving a distance of 100m between compatible devices. Fiber optic media converters can be used to increase the distance between devices to over 40km.

    BSS BLU-325 Features:

    • Four Input / Output Card Slots
    • Configurable Inputs / Outputs
    • Analog Inputs (with Phantom Power per Channel)
    • Analog Outputs
    • Digital Inputs (AES/EBU and S/PDIF)
    • Digital Outputs (AES/EBU and S/PDIF)
    • AEC Inputs (with Phantom Power per Channel)
    • Telephone Hybrid Card
    • Rich Palette of Logic Objects
    • Ethernet AVB Audio
    • 256 Channel, Low Latency, Fault Tolerant Digital Audio Bus
    • Clear Front Panel LED Indication
    • Informative Front Panel Display
    • Bi-Directional Locate Functionality
    • 12 Control Inputs and 6 Logic Outputs for GPIO Integration
    • Soundweb London Interface Kit for Third Party Control System Integration (Documentation)
    • HiQnet Device
    • Configuration, Control and Monitoring from HiQnet London Architect

    BSS BLU-325 Specification:

    • Chassis: 19" (single rack space)
    • Custom I/O (card based): yes
    • Analog Inputs: up to 16
    • Digital Inputs: up to 16
    • AEC Inputs: up to 16
    • Analog Outputs: up to 16
    • Digital Outputs: up to 16
    • Telephone Connection: up to 4
    • Max Inputs/Outputs: 16
    • Config: Software
    • LCD Display: yes
    • Logic Processing: yes
    • RS-232: yes
    • GPIO: yes
    • Signal Processing (MHz): no
    • Cobranet: no
    • AVB: yes
    • Dante: no
    • SWL Digital Audio Bus: 256
