dB Technologies VIO S218 Active Bassreflex Subwoofer

dB Technologies VIO S218 Active Bassreflex Subwoofer Overview: The perfect partner for VIO L212 in larger sound reinforcement applications A simple, effective dual sub configuration designed to enhance the reproduction of the lowest frequencies, boosted by an advanced DSP control and complete network capability.

Built For Touring Featuring a dual 18" subwoofer pairing in a voluminous bass-reflex housing, VIO S218 encompasses a vigorous audio performance and a ultra low frequency punch, extending down to 28 Hz: the perfect bottom-end addition to large VIO L212 sound reinforcement systems Real Time Control As a default, VIO S218 is equipped with dBTechnologies RD-Net card, for real time remote control via Aurora Net software.

Furthermore, the preamplifier is ready for future upgrades with Audinate DanteTM AoIP protocol To help users in this configuration, S218 comes with built-in technologies: Near Field Communication (NFC™) proximity sensors are used to determine the position of each box within an array.

This technology, together with a hi-brightness LED bulb on the front of the enclosure, contributes to help the user to recognize, identify and match each box physical position on the remote control software Aurora Net The amp also allows users to run auto-test on electronics and transducers before and after use and a real time impedance control.

This unique system ensure tour-grade reliability and remote control over your entire PA’s health Cardioid Preset A cardioid stack preset button automatically process the sound of the backward sub in gradient inverted stack configurations, in order to reach maximum cancellation of the rear side.

The on-board delay module allows VIO S218 to reach a max 9.9ms delay with 0.1 ms steps Specifications Speaker Type: Active Bassreflex subwoofer Acoustical Data Frequency Response [- 10 dB]: 27 Hz (HPF) Frequency Response [- 6 dB]: 28 Hz to cut frequency (Xover dependent) Max SPL: 143 dB LF: 2x18” Neodymium Voice Coil LF: 4” Directivity: Omnidirectional Amplifier Amplifier: 3200 W RMS [2x 1600 W RMS Class-D Digipro G4] Cooling: Passive convection, internal fan Power Supply: Full-range SMPS with PFC (100V~-240V~, 50-60Hz) Processor Controller: DSP 32 bit AD/DA Converter: 24 bit/96 kHz Limiter: Peak, RMS, Thermal Delay Option: 0 - 9.9 ms internal | steps of 0.1 ms [on-board] Crossover Frequency LF-HF: Selectable 60-110 Hz + Full Range (8 steps) LF-Xover out slope: 24 dB/Octave Input Signal Input: 1 x XLR balanced, 1 x RJ45 Link (RDNet) Signal Output: 1x XLR balanced, 1 x RJ45 Link (RDNet) Power Socket 1x PowerCON TRUE1 In 1x PowerCON TRUE1 Out Controls 1x Input Attenuation Rotary Encoder 2x Delay Rotary Encoder (0-9.9 ms) 1x Polarity Inversion Switch (0° or 180°) 1x Cardioid mode Switch 1x X-Over Frequency Rotary Encoder (8 steps) Special Features NFCTM and Frontal LED Identification System 380V Resistant SMPS IPOS Intelligent Power-On Sequence Opto-isolated floating pre-amp System Test (transducers diagnostics) Mechanics Housing: Multiplex plywood - Polyurea painting Handles: 4x Side.

Aluminium Rigging Points: 2x Pick Points on top for DRK-210 rigging frame Dimensions Width: 1300 mm (51.18 in) Height: 520 mm (20.47 in) Depth: 800 mm (31.5 in) Weight: 85.6 kg (188.72 lbs).
