Neumann KM 150 Miniature Microphone

Neumann KM 150 Miniature Microphone

This item is out of stock


Buy Neumann KM 150 Miniature Microphone online in India at the best price with free shipping from BAJAAO - India's music equipment superstore.

Neumann KM 150 Miniature Microphone

The AK 50's attenuation of sound incidence from the side or rear is about 10 dB, with minimum sensitivity at an angle of 120 degrees. Often used, as XY stereo pair, on Overheads, on Toms, in situations that are susceptible to acoustic feedback, to attenuate unwanted sound of nearby instruments , for recording of speech, as in TV, movie and video productions, PA systems.

The variable condenser miniature microphone system consists of several active microphone capsules with different directional characteristics, an output stage, and numerous accessories. Currently there are seven active capsules available: omni diffuse- field equalized, omni free-field equalized, cardioid, wide-angle cardioid, cardioid with bass roll-off, hypercardioid, and figure-8. Through the modular construction of mic capsules and the output stage it is very easy to adapt the system to a wide range of applications. The mic becomes nearly invisible during work with cameras (film, video), on stage, or suspended from the ceiling in a concert hall. An active capsule can also be screwed directly onto the output stage. The result is a compact miniature microphone. The microphones are only 92 or 110 mm resp. long and 22 mm in diameter. They consist of the condenser capsule and the output stage. Both parts can be unscrewed from each other. The capsules attach to cables, capsule extensions, swivel mounts, table stands, goose-necks, stereo mounts, and hangers. Therefore, it is very easy to adapt the system to a wide range of applications. The active capsule itself is only 35 or 47 mm resp. long. The KM 100 output stage and the active microphone capsule may be separated by up to 50 m of interconnecting cable. These cables are 3 mm in diameter, and therefore very inconspicuous.

Neumann KM 150 Features:

  • Miniature microphones with 7 exchangeable capsules
  • Active capsules, detachable up to 50 m from the output stage
  • Great variability through capsule extensions and goosenecks
  • Switchable 10 dB pre-attenuation enables sound pressure levels up to 152 dB without being overloaded.
  • Transformerless circuitry
  • Extensive accessories
  • The KM 100 output stage has a 3-pin XLR connector.

Neumann KM 150 Includes:

  • Microphone KM 150 consisting of KM 100 and AK 50
  • Windscreen WNS 100 or WNS 120
  • Stand mount swivel SG 21 bk
  • Wooden box.

Neumann KM 150 Specifications:

  • Acoustical operating principle: Pressure gradient transducer
  • Directional pattern: Hypercardioid
  • Frequency range: 20 Hz - 20 kHz
  • Sensitivity at 1 kHz into 1 kohm: 10 mV/Pa
  • Rated impedance: 50 ohms
  • Rated load impedance: 1000 ohms
  • Equivalent SPL CCIR 468-3: 27 dB
  • Equivalent SPL DIN/IEC 651: 16 dB-A
  • S/N ratio CCIR 468-3: 67 dB
  • S/N ratio DIN/IEC 651: 76 dB
  • Maximum SPL for THD 0.5%: 142 dB
  • Maximum SPL for THD 0.5% with preattanuation: 152 dB
  • Maximum output voltage: 10 dBu
  • Dyn. range of the mic. amplifier DIN/IEC 651: 124 dB
  • Supply voltage: 48 V ± 4 V
  • Current consumption: 2 mA
  • Matching connector: XLR 3F
  • Weight: 80 g
  • Diameter: 22 mm
  • Length: 92 mm.
