Superlux WH5 Dynamic Microphone

Superlux WH5 Dynamic Microphone Overview: Professional microphone users tend to use different microphones for different sound sources so that to achieve a desired sound character With Superlux WH5 microphone, a trilogy concept microphone with 3 different capsules built-in so that the user can select one of the capsule for the sound he preferred.

Classical appearance integrated with latest microphone technology for artist demanding a unique "oldies" appearance with "goodies" music performance A 3-position switch on the back to switch between percussion, instrument, or vocal setting.

On/off switch on the base for artist to control the sound at his/her reach Features: 3 different frequency response capsules in one body.

Always a sound meet your demand Typical application for percussion, instrument and vocal Classical appearance, latest technology On/off control, and 3-position capsule selection control Internal shock mount for reducing handling noise 5/8" thread of standard microphone stands Tilt limit, and position set mechanism for 45 degree forward and 80 degree backward setting Chrome polish finish for long-term operation and collection Includes Table Stand D1 Specifications: Type: Dynamic Microphone Polar pattern: Unidirectional (Super Cardioid), rotationally symmetrical about microphone axis, uniform with frequency Frequency Response: Drum: 30 to 10,000 Hz Instrument: 20 to 12,500 Hz Vocal: 50 to 16,000 Hz Sensitivity (at 1,000 Hz Open Circuit Voltage) Drum: -62dBV/Pa (0.8mV/Pa) Instrument: -55dBV/Pa (1.8mV/Pa) Vocal: -54dBV/Pa (2.0mV/Pa) 1Pa=94dB SPL Rated impedance: 200Ω Max.

SPL (1, 000 load) Ω Drum: 147 dB SPL Instrument: 134 dB SPL Vocal: 134 dB SPL THD 1% 1kHz Polarity: Pin 2 output positive voltage (related to pin 3) when diaphragm receives positive pressure (Diaphragm moving inward) Connector: Integral 3 pin male XLR type Finish: Metal construction with chrome gloss finish Environmental conditions: The WH5 operates between -10 to +50 (14 to 122 ) with relative humidity between 0 to 95%.

Dimensions: Φ80.0mm x 76.5mm x 200mm (3.15in.x3.00in.x7.87in.) Net weight: 750g (26.45oz.).
