Tascam DP-32SD Portable Digital Mixer

SKU : TAS-DP32SD
Save 12%
Rs. 55,232
Rs. 48,604

Or Just Rs. 8,101 Rs. for 6 months
0%* Interest EMI available for all major credit cards and Bajaj Finserv Card. Call +91-22-61235384

Limited Period Offer : Don't forget to use Coupon Code: " INSTANT4 " at checkout for additional 4% discount.

Buy Bajaao Premium Warranty at Affordable Prices. Offering door to door warranty service. T&C

DP-32SD OVERVIEW
TASCAM’s DP-32SD Digital Portastudio records an unmatched 32 tracks to solid-state media. Up to eight tracks can be recorded at a time through its combination XLR and 1⁄4” combo jacks. Input processing like compression and limiting are available during recording, as well as guitar amp simulation and multi-effects for use with the instrument-level input. A color LCD and channel strip knobs make mixing fast and creative. The included 4GB SD card can be replaced with up to 32GB SCHC media or swapped with other cards between projects. With its great sound, powerful features and easy operation, the DP-32SD is TASCAM’s biggest Portastudio yet.

Twelve Mono and Twelve Stereo Tracks
The DP-32 has 12 selectable tracks between MONO or STEREO. Use a STEREO track for recording synthesizer, or set the track to MONO when recording guitar or vocal. Not only that, you can create ideal settings for each track. (set #9 to #12 STEREO, then set #13 to #22 MONO) If all tracks are set to MONO the DP-32 becomes a 20-track multi track recorder

21 faders eliminates layer structuring
The DP-32, even with the high number of tracks, is one of the easiest multi-track recorders in the market to use. The The DP-32SD has 20 track-faders and one master fader. You can control any track with ease.

The 3.5" full-color LCD and the self-illuminated buttons increase visibility
The DP-32SD has a 3.5" LCD screen and select self-illuminated buttons, making it easy to view your entire creative process. Some of the illuminated buttons include (SOURCE, SELECT, REC, MUTE).

12 rotary knobs linked to the LCD to help increase easy operation
The DP-24/32 have similarly employed rotary knobs to control qualities such as EQ, Effect Send and other related features.

Utilizing SD/SDHC media ensures confident recording, free from shock due to loud sounds
The DP-32SD uses SD/SDHC media. These cards provide secure shock resistance due to the absence of any moving parts. The file format in the DP-32SD is FAT 16 or 32. You can transfer the recorded files to your computer via USB.

8 XLR/TRS inputs, 8 channel recording, 32 tracks playback
The DP-32SD has 8 XLR-TRS combo inputs. You can record up to eight sources at one time.

INPUT A-H and each track are equipped with 3-band EQ
The equalizer for each track and each input are independent from other effects. Record like any professional studio with EQ for each individual track.

8 dynamics effects, guitar effects and mix-down effects
Use up to 8 dynamics effects at once, one for each input source. For example, utilize the built-in compressor effect for your bass, guitar and drums tracks. In addition, the DP-32SD have multiple guitar and mixing effects.

Built-in Digital Mastering
The DP-32SD is equipped with mastering effects for finihsed-sounding mixes. There is no need for computers when recording and mixing. The mastering effects section includes a Multi-Band Compressor, EQ, Noise-Shaping Dither, and a Normalize Effects. You can create a high-quality 2-track master file for transfer to your computer to burn a CD or share online.

The headphone amplifier has a high output power of 70mW/ch
The headphone amplifier provides easy monitoring in loud environments such as a rehearsal studios or live performance.

Features at-a-glance
  • Simultaneous 32 track playback
  • 8 mono tracks + 12 mono/stereo selectable tracks
  • Mounted TMSS (TASCAM Multi Stage Sampling rate converter) provides high-quality sampling rate conversion
  • Integrated 40-input mixer to mixdown the 32 playback tracks with the 8 inputs or for bouncing
  • Simultaneous 8 track recording
  • 16 or 24 bit, 44.1 or 48 kHz recording
  • 8 XLR/TRS combo connectors
  • Phantom power supply for all inputs
  • High-impedance input available (INPUT-H)
  • Stereo RCA pin-jack output
  • 2 effect send outputs (1/4" TS jack)
  • 70mW/ch headphone amplifier
  • Peak-hold function at a level meter of the LCD
  • Sub-frame editing
  • Remote connector for optional RC-3F footswitch
  • INPUT A-H and each track are equipped with 3-band EQ
  • Automatic punch in/out
  • Various edit functions(COPY INSERT, COPY PASTE, MOVE INSERT, MOVE PASTE, OPEN, CUT, SILENCE, CLONE TRACK, CLEAN OUT)
  • Undo and Redo function with Undo history
  • 8 dynamics effects
  • Guitar effects
  • Mix-down effects
  • Mastering Effects
  • Track bounce function
  • Virtual tracks(8 virtual track per one track)
  • Locate mark up to 99 at one song
  • File transferring via USB2.0
  • Chromatic tuner
  • Metronome
  • Dedicated AC adapter included(TASCAM PS-1225L)
  • 8 mono and 12 mono/stereo selectable tracks
  • 21 faders (20 track-faders and one master fader)

Tascam DP-32SD Specifications:

Recording Media : SD (512MB – 2GB) / SDHC card (4GB – 32GB)
File System : SD card:FAT16 / SDHC card:FAT32

INPUT A-H
XLR
Connector : XLR-3-31(1:GND, 2:HOT, 3:COLD), Balanced
Input impedance : 2.4k ohms
Nominal input level : -14dBu
Maximum input level : +2dBu

TRS
Connector : 6.3mm(1/4")TRS phone-jack, Balanced
Input impedance : 22k ohms or more
/ 1M ohms(when INPUT H, GUITAR selected)
Nominal input level : +4dBu
Maximum input level : +20dBu

STEREO OUT
Connector : RCA pin-jack, Unbalanced
Output impedance : 200 ohms
Nominal output level : -10dBV
Maximum output level : +6dBV

EFFECT SENDS :
Connector : 6.3mm(1/4")TS phone-jack, Unbalanced
Output impedance : 200 ohms
Nominal output level : -10dBV
Maximum output level : +6dBV

MONITOR OUT :
Connector : 6.3mm(1/4")TRS phone-jack, Balanced
Output impedance : 200 ohms
Nominal output level : -2dBu
Maximum output level : +14dBu

PHONES
Connector : 6.3mm(1/4")TRS phone-jack
Maximum output level : 70mW + 70mW (THD+N 0.1% or less, 32 ohms loaded)

USB :
Connector : USB Mini-B type 4-pin
Format : USB2.0 High-Speed mass-storage class

REMOTE
Connector : 2.5mm TRS jack
Power : Dedicated AC adapter (TASCAM GPE248-120200-Z, included)
Power consumption : 12W (when phantom power supplying)
Dimensions : 514(W)×104(H)×340(D)mm / 20.2"(W)×4.1"(H)×13.4"(D)
Weight : 6.2kg / 13.67 lb
Operating temperature : 5 to 35˚C / 41 to 95˚F
Accessories : AC adapter, 4GB SD card, warranty card, owner's manual

Operating system requirements

Windows :
OS : Windows XP, Windows Vista, Windows 7, Windows 8
CPU : Pentium 300MHz or more
Memory : 128MB or more
USB : USB2.0

Macintosh :
OS : Mac OS X Jaguar (V10.2),Mac OS X Panther (V10.3),Mac OS X Tiger (V10.4),Mac OS X Leopard (V10.5),Mac OS X Snow Leopard(V10.6.8),OS X Lion(V10.7),OS X Mountain Lion(V10.8)
CPU : Power PC, iMAC, G3, G4 266MHz or more
Memory : 64MB or more
USB : USB2.0

Audio performance
Frequency response : 20Hz to 20kHz (+/-1dB, INPUT to STEREO OUT/EFFECT SENDS/MONITOR OUT)
S/N Ratio : 90dB or greater (INPUT to STEREO OUT/EFFECT SENDS/MONITOR OUT)
THD : 0.01% or less (INPUT to STEREO OUT/EFFECT SENDS/MONITOR OUT)
