TC Helicon PERFORM-VK Vocal Processor

TC Helicon PERFORM-VK Vocal Processor Overview: HARMONIZE YOUR SOUND Whether you use audio or MIDI from your keyboard, our vocal effects engine captures your chord information and creates up to two voices of real time harmony to accompany you If you like to get more complex vocal output, MIDI note driven harmony is also available with direct control of up to 8 simultaneous harmony voices.

SIMPLICITY IS KEY Perform-VK pairs perfectly with your keyboard or stage piano to give you stand out vocal effects, mixing and USB multi track audio in one small, easy to use unit CREATIVE CONTROL AT YOUR FINGERTIPS Perfrom-VK allows you to take control of your sound, giving you the power to simulate a physical space with REVERB or put it on repeat with ECHO simply by hitting a button.

IN THE STUDIO OR ON STAGE When it’s time to hit the studio, Perform-VK’s 4 in, 8 out USB audio capability gives you all the flexibility you need to create great recordings in no time Simultaneously capture dry and wet versions of your vocals, along with harmony voices and your keyboard audio.

POLISH YOUR PERFORMANCE Add instant clarity with the TONE button Adaptive EQ, compression, gating and de-ess provide you with professionally polished vocals that ensure you always cut through the mix.

Turn on Anti-feedback and your Perform-VK will be on the prowl for pesky speaker squealing, knocking it out quickly if it does occur The PITCH button provides a helping hand by pushing you to the nearest half-note with subtle pitch-correction.

SET AND FORGET Perform-VK removes much of the complexity involved with most audio gear In addition to Tone and Anti-Feedback the Automatic Microphone Input Gain means that setup is as straightforward as plugging in a mic and holding the SET button while you sing.

Boom, ready to rock It even clips onto your mic stand right where you need it.

JUST BEAM IT Out of the box it’s easy to dial in a timeless, premium vibe using the onboard Double, Reverb, and Echo sounds Go deeper with the free Perform-VK app for your smartphone.

Pick and choose from a library of pre-made sounds including HardTune, harmony, megaphone, and instantly transform your sound Simply “beam” the sounds directly from your phone to the PRESET buttons and you’re good to go – no need for accessories or even a wireless or Bluetooth connection! MAKE IT A HIT Most presets you beam or download come with a "HIT" function.

HIT helps you build intensity into your performances by adding additional layers to the preset by simply pressing the preset button a second time (it turns blue instead of green) This is ideal for creating striking choruses or highlighting a certain phrase.

VOICESUPPORT Perform-V will evolve with you VoiceSupport, our free desktop app, gives you the latest firmware updates and maintains your personal database of presets that you have beamed.

All you need is a Mac or Windows computer with a USB input PRACTICE WITHOUT A MIC When you're not beaming presets to it, the embedded RoomSenseTM mic doubles as a handy vocal input for headphone sessions when the ideas come faster than getting up and plugging in your regular mic.

EXTEND YOUR CONTROL HANDS ON Remote control your sounds with a mic engineered for the sonic realities of modern vocal performance Add the TC-Helicon MP-75 or MP-76 microphone and use the groundbreaking Mic Control™ buttons to roam the stage freely.

HANDS OFF While Perform-V is designed for a hands-on experience, there may be times when you're playing an instrument or otherwise keeping those fingers occupied For these occassions, you can add a Switch-3 or Switch-6 accessory pedal to let your feet take control.

Features: Ultimate stand-mount vocal processor gives you simple and fast studio-quality sound with expandable effects and keyboard input / output Built-in Adaptive Tone plus sweet harmony, reverb, and echo effects let you quickly create pro studio quality vocals Beam additional effects onto three preset buttons, choosing from hundreds of available presets, to perfectly fit your musical style 1/4-inch stereo keyboard input / output lets you have more control at your fingertips with MIDI note and continuous control entry Multi track 4-in, 8-out USB audio interface for easy recording Easy HIT function in beamed presets turns on layered effects with a single Intelligent mic input gain for quick and painless setup Powerful Anti-Feedback stays on alert for feedback and stops it automatically Effortless auto-chromatic pitch correction helps you sing in tune RoomSense mic lets you practice without a mic and automatically controls harmony Central knob with four-color light ring for easy editing of sounds, settings, mix levels and more Compatible with remote Mic Control and with optional foot switching through TC HELICON MP-75 or MP-76 Modern Performance Vocal Microphones or Sennheiser* e835 FX microphone and Switch-3 or Switch-6 foot switches Designed and engineered in Canada Specifications: CONSTRUCTION Extremely durable ABS plastic body Soft touch elastomer backlit buttons Punch-cut metal connection panel Rubberized footings Unique built-in mic-stand grip SIZE & WEIGHT H x W x D: 3.6 inches (92 mm) x 6.6 inches (167 mm) x 6.7 inches (170 mm) Weight: 0.93 lb (0.48 kg) WHAT'S IN THE BOX? Region specific power supply USB cable User guide INCLUDED EFFECTS VOCAL SOUNDS Reverb Echo Harmony Double* Megaphone* HardTune* µMod* *beamable via the free Perform-V app for iOS and Android VOCAL SHAPING Adaptive Tone Pitch Correction CONTROL Direct access to high-quality Harmony, Reverb and Echo effects Central encoder knob with 4-color light ring for easy editing of sounds, settings, mix levels and other parameter control Mic Input Gain setup Adaptive Tone on/off Anti-Feedback on/off Pitch correction on/off and amount 48V phantom power for condenser mics on/off Dedicated, custom preset storage and recall buttons with HIT on/off Headphone output level All effects on/off via Talk Tap tempo Mic Control™ via MP-75 or MP-76 microphones Stereo Audio I/O for painless integration with your rig.

MIDI connection ANALOG INPUTS MICROPHONE INPUT Connector: XLR Input Impedance: 6.7 kOhm balanced Max Input Level: -29 dBu to +2.5 dBu EIN @ max gain, 150 Ohm Zsource: -127 dBu A-weighted Phantom Power: +48V A to D Conversion: 24 bit, 128 x oversampling bitstream, 115 dB SNR A-weighted AUX INPUT Connector: 1/8" stereo unbalanced mini jack (summed with Inst Input) Input Impedanc\n Input Impedance: 5 kOhm \n Max Input Level: +2.5 dBu \n A to D Conversion: 24 bit, 128 x oversampling bitstream, 102 dB SNR A-weighted \n \n INST INPUT \n \n Connector: ¼” TRS left and right bal/unbal (summed with Inst Input) \n Input Impedance: 10 kOhm balanced, 5 kOhm unbalanced \n Max Input Level: +5.8 dBu \n A to D Conversion: 24 bit, 128 x oversampling bitstream, 102 dB SNR A-weighted \n \n ANALOG OUTPUTS MAIN OUTPUT \n \n D to A Conversion: 24 bit, 128 x oversampling bitstream, 115 dB SNR A-weighted \n Connectors: ¼” TRS, impedance balanced left and right \n Output Impedance Balanced/ Unbalanced: 200/100 Ohm \n Output 0 dBFS: +14 dBu \n Dynamic Range: > 112 dB, 20 Hz to 20 kHz \n Frequency Response: +0.50/-0 dB, 20 Hz to 20 kHz \n \n HEADPHONE OUTPUT \n \n Connector: 1/8" mini stereo jack CONTROL USB: USB-B (Preset Management, Firmware Updates, USB Audio) Pedal: 1/4″ TRS phone jack Mic Control using TC-Helicon MP-75 and MP-76 Microphones or Sennheiser e 835 FX mic MIDI IN: DIN5 MIDI-compliant input, opto-isolated SAFETY AND REGULATIONS POWER External Power Supply.

Mains Voltage Input: 100 to 240 VAC, 50 to 60 Hz (auto-select) 12V DC 1A max output Power Consumption: < 14 W SAFETY EMC – Complies with: EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B Safety – certified to: IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA ENVIRONMENT Operating Temperature: 32° F to 122° F (0° C to 50° C) Storage Temperature: -22° F to 167° F (-30° C to 70° C) Humidity: Max 90 % non-condensing Made in Canada.
