RME Fireface UFX USB/FireWire Audio Interface with DSP Mixer

RME Fireface UFX USB/FireWire Audio Interface with DSP Mixer

EMI starts from Rs. 8,014.45. Click here for options.


RME Fireface UFX USB/FireWire Audio Interface with DSP Mixer

When you demand uncompromising performance plus several I/O options from your audio interface, then you need RME's Fireface UFX. This outstanding USB 2.0/FireWire interface gives you 30 input and 30 output channels, digitally controlled preamps, a range of digital I/O options, and an onboard word clock. You'll love the Fireface UFX's included TotalMix FX DSP mixer and signal router; it maximizes what the Fireface UFX can do while it improves your workflow. The full-color front-panel display lets you meter plus view parameters and menus. The Fireface UFX can even be configured for standalone use as a preamp, a monitor mixer, an AD/DA converter, and more.

If it's I/O flexibility you're seeking, then look no further than the Fireface UFX! You don't just get 12 channels of premium analog I/O; you also get AES/EBU, ADAT, S/PDIF, and MIDI I/O. You also get a rock-solid onboard word clock. RME did an outstanding job of making the Fireface UFX the ideal centerpiece for your studio setup. This incredible single-rackspace interface even includes built-in monitoring control. When you couple that functionality with the TotalMix FX DSP mixer/router, you have a total studio solution.



RME Fireface UFX Features:

  • 24-bit/192kHz
  • 30 Input / 30 Output channels
  • 12 x Analog I/O
  • 4 x Mic/Instrument Preamp, digitally controlled
  • 1 x AES/EBU I/O
  • 2 x ADAT I/O (or 1 x ADAT I/O plus 1 x SPDIF I/O optical)
  • 1 x Word Clock I/O
  • 2 x MIDI I/O
  • 1 x FireWire 400
  • 1 x USB 2.0
  • TotalMix FX DSP mixer/ signal router.



AD, Line-in 1-8, rear:

  • Signal to Noise ratio (SNR): 110dB RMS unweighted, 113dBA
  • Frequency response @ 44.1kHz, -0.1dB: 5Hz - 21.5kHz
  • Frequency response @ 96kHz, -0.5dB: 5Hz - 45.5kHz
  • Frequency response @ 192kHz, -1dB: 5Hz - 66.5kHz
  • THD:
  • THD+N:
  • Channel separation: > 110dB
  • Input: 1/4" TRS jack, electronically balanced
  • Input sensitivity switchable to Lo Gain, +4dBu, -10dBV
  • Input level for 0 dBFS @ Lo Gain: +19dBu
  • Input level for 0 dBFS @ +4 dBu: +13dBu
  • Input level for 0 dBFS @ -10 dBV: +2dBV



Microphone In 9-12, front:

  • Input: XLR, electronically balanced
  • Signal to Noise ratio (SNR): 112dB RMS unweighted, 115dBA
  • Gain range: 65dB
  • Maximum input level, Gain 0dB: +12dBu



Instrument In 9-12, front:

  • Input: 1/4" TS jack, unbalanced
  • Signal to Noise ratio (SNR): 112dB RMS unweighted, 115dBA
  • Gain range: 55dB



DA, Line Out 3-8, rear:

  • Dynamic range (DR): 115dB RMS unweighted, 118dBA
  • Frequency response @ 44.1kHz, -0.5dB: 5Hz - 22kHz
  • Frequency response @ 96kHz, -0.5dB: 5Hz - 34kHz
  • Frequency response @ 192kHz, -1dB: 5Hz - 50kHz
  • THD: -104dB,
  • THD+N: -100dB,
  • Channel separation: > 110dB
  • Output: 1/4" TRS jack, servo-balanced
  • Output impedance: 75 ohm
  • Output level switchable Hi Gain, +4 dBu, -10dBV
  • Output level at 0dBFS @ Hi Gain: +19dBuB
  • Output level at 0dBFS @ +4dBu: +13dBu
  • Output level at 0dBFS @ -10dBV: +2dBV



DA - Stereo Monitor Output XLR (1-2):

  • Output: XLR, balanced
  • Output level switchable 24dBu, Hi Gain, +4dBu, -10dBV
  • Output level at 0dBFS @ 24dBu: +24dBu



DA - Stereo Monitor Output Phones (9-12):

  • Output: 1/4" TRS stereo jack, unbalanced
  • Maximum output level at 0dBFS, High: +13dBu
  • Maximum output level at 0dBFS, Low: +2dBV
  • Output impedance: 30 ohm



AES/EBU:

  • XLR, transformer-balanced, galvanically isolated, according to AES3-1992



ADAT Optical:

  • 4 x TOSlink, format according to Alesis specification
  • Standard: 2 x 8 channels 24-bit, up to 48kHz
  • Double Speed (S/MUX): 2 x 4 channels 24 bit 96kHz
  • Quad Speed (S/MUX4): 2 x 2 channels 24 bit 192kHz



Word Clock:

  • BNC, switch for internal termination 75 ohm



RME Fireface UFX Specifications:

  • Computer Connection Type: USB
  • Form Factor: Rackmount
  • Simultaneous I/O: 30 x 30
  • A/D Resolution: 24-bit/192kHz
  • Built In DSP/FX: Yes
  • Number of Audio Inputs: 12
  • Audio Inputs Types: 4 x Combo (Mic/Line), 8 x TRS
  • Number of Audio Outputs: 12
  • Audio Output Types: 2 x XLR (Main), 9 x TRS, 1 x TRS (Headphone)
  • Number of Digital Inputs: 18
  • Digital Input Types: 2 x ADAT (Optical/8 Ch.), 1 x AES/EBU (XLR)
  • Number of Digital Outputs: 18
  • Digital Output Types: 2 x ADAT (Optical/8 Ch.), 1 x AES/EBU (XLR)
  • Number of Preamps: 4
  • Phantom Power: Yes
  • MIDI I/O: 2 x In, 2 x Out
  • Clock I/O: 1 x Word Clock (In/Out via BNC)
  • Bus Powered: No
  • Rack Units: 1U
  • Depth: 9.5"
  • Width: 19"
  • Height: 1.75"
  • Weight: 6.6 lbs.
