Black Lion Audio Revolution 2x2 USB C Audio Interface Overview: Black Lion Audio have been revered as the “king of audio mods” for years, and have modded countless recording interfaces over the years But since the very beginning, we’ve been asked when we would create our own interface.
So, we planned, engineered, and worked — all in secret, for years It took an impressive amount of design to revolutionize bus-powered, studio-grade interfaces.
Now we are responding with Revolution 2×2: the ultimate in portable recording interfaces Revolution isn’t another run-of-the-mill interface from big brother — it’s the interface the world has always asked for.
Don’t just settle for “the cheap and portable” – get an interface that can do more than just start a demo, but actually finish a top-level record from start to finish Features 24bit, 192KHz USB C interface Bus Powered Macro MMC clocking Analog circuit design utilizing Nichicon, Vishay and Wima capacitors PG-i power filtering technology USB Class Compliant Revolution Software Suite Technical Specifications Mic Input Input Impedance = 3KΩ (balanced) Gain Range = 55dB Frequency Response = 20Hz – 20KHz +/- 0.25dB THD + N = .00098% (@12dB Gain) Dynamic Range = 116dB (A-Weighted) Crosstalk = < 100dB Line Input Input Impedance = 14KΩ (balanced) Maximum Input = 20dBu Gain Range = 55dB Frequency Response = 20Hz – 20KHz +/- 0.25dB THD + N = .0022% (Min Gain) Dynamic Range = 126dB (A-Weighted) Crosstalk = < 100dB Line Outputs Output Impedance = 95Ω (balanced) Max Output Level = 12dBu Frequency Response = 20Hz – 20KHz +/- 0.25dB THD+N = .002% (@ +10dBu) Dynamic Range = 106dB** Instrument Input Input Impedance = 1MΩ (unbalanced) Gain Range = 55dB Frequency Response = 20Hz – 20KHz +/- 0.25dB THD + N = .00114% (@ 0dBu) Dynamic Range = 103dB (A-Weighted) Crosstalk = < 100dB Headphone Outputs Output Impedance = 2.5Ω Maximum Signal Output = 9.3dBu Frequency Response = 20Hz – 20KHz +/- 0.5dB Made in China.
