SPL Goldmike 9844 2 CHannel Microphone Preamp

Write a review
| Ask a question
SKU : SPL-GOLDMIKE9844
Sold out
Rs. 83,400
Rs. 68,700

   Free Delivery available on this product.

Buy Bajaao Premium Warranty- With Accidental Damage Cover & Free Pickup and Return T&C
Seen It For Less? Learn More
SPL Goldmike 9844 2 CHannel Microphone Preamp Overview:

The GoldMike is a dual-channel, dual-powered microphone preamplifiercombining pure solid state and Class A tube stages in the preamplification chain for best-of-both-worlds results. With the GoldMike preamplification up to 72 dB is possible – a full tube preamp can’t begin to reach these values. The tube stage provides a constant, additional gain of +6 dB, so that the tube sound component remains constant regardless of amplification. The familiar sound qualities of tubes are
combined with modern demands for high and linear amplification as well as effective common mode rejection. An enormous dynamic range of 111 dB and quiet
operation qualifies the GoldMike as an ideal partner for high-resolution HD recording systems. The fast rise time of tubes ensures an airy and open tonal character. Two separate Class A mono blocks guarantee perfect channel separation and best spatial definition for stereo recordings—that’s why the GoldMike excels even in difficult choral group recordings.

Features:
  • Excellent sound optimizing already during recording: The FLAIR function enhances detail,
  • intelligibility, presence and penetration.
  • Tube Warm-Up circuitry
  • Two illuminated VU meters
  • Star point grounding for best signal quality
  • Subsonic filter (80 Hz), phase reverse switch, padding at -30 dB
  • Selectable 48V phantom power from separately filtered power supply
  • Cleanly filtered power supply with huge power reserves: 6000 µF in the main power supply and 400 µF in the tube power supply.
  • XLR inputs, XLR and jack outputs, can be used singly or in parallel
Specifications:
  • Frequency response: 10 Hz-100 kHz, 0.5 dB
  • Common mode rejection: - 80 dBu @1 kHz, -73 dBu @10 kHz
  • Distortion:
  • Input signal (-30 dB): Gain (30 dB), Distortion (0.175%)
  • Input signal (-60 dB): Gain (60 dB), Distortion (0.2%)
  • Measured noise
  • Signal-to-noise ratio Gain A-weighted
  • Gain: 72 dBu - A-weighted: 62 dBu
  • Gain: 60 dBu - A-weighted: 71 dBu
  • Gain: 30 dBu - A-weighted: 85.6 dBu
  • Dynamic range: 111 dBu
  • Noise figure: 3.8
  • E.I.N.: 135.4 dBu
  • Input specifications
  • Instrumentation amplifier, electronically balanced (differential), transformerless
  • Input impedance: 1.8 kOhm
  • Max. input level: 135.4 dBu
  • Output specifications
  • XLR output: Instrumentation amplifier, electronically balanced (differential), transformerless
  • Nom. XLR output level: 6 dB
  • Max. XLR output level: 25.4 dB
  • Nom. jack output level: 0 dB
  • Max. jack output level: 19.4 dB
  • Output impedance (XLR/jack): < 600 Ohm
  • Power supply
  • Toroidal transformer: 20 VA
  • Fuses (230/115 V): 315 mA (230 V/50 Hz), 630 mA (115 V / 60 Hz)
  • Voltage selection switch: 115 V / 230 V, GND lift switch
  • Dimensions
  • Standard EIA 19”/2U: 482 x 88 x 158 mm
  • Weight: 3.05 kg
